FK IT coating head
The FK IT coating head for intermittent and continuous coating application of hot melt adhesive onto sheets and webs of material, with masking technology for quick format changes.
FK IT is a range of coating heads for intermittent and continuous application of low to medium viscosity thermoplastic hot melt adhesives. A dual-action solenoid valve with a negative-closing jetting element ensures a precise cut-off and consistent coating weight from start to finish, even at high production speeds and with rapid format changes.
Key benefits of the FK IT coating head
- precise cut-off and consistent coating weight from start to finish
- quick and inexpensive format changes thanks to masking technology
- easy integration thanks to a compact design and top-mounted connection
- constant adhesive temperature right up to the nozzle
- no nozzle clogging thanks to the integrated filter
- operator safety thanks to CoolTouch insulation
- 180° rotating nozzle
FK IT heads apply adhesive both to continuous webs of material (roll-to-roll) and to individual sheets in folding machines – combined with a feed roller or a specially developed support unit. Masking technology allows quick and inexpensive format changes: different mask shapes and thicknesses flexibly adjust the application pattern and increase process repeatability.
A compact design with a top-mounted connection simplifies integration into the machine, an integrated filter prevents nozzle clogging, and optional CoolTouch insulation protects operators from burns. The nozzle rotates 180° with or against the direction of travel, so the head can also be mounted in hard-to-reach places.
| Temperature range | 20–200 °C |
| Adhesive pressure | max. 100 bar |
| Adhesive | thermoplastic adhesives |
| Adhesive viscosity | 100–10,000 mPa·s |
| Switching frequency | 125 Hz |
| Application width | FK IT 25: 3–25 mm / FK IT 50: 25–50 mm / FK IT 75: 50–75 mm / FK IT 100: 75–100 mm / FK IT 125: 100–125 mm |
| Minimum application time | 4 ms |
| Minimum gap | 4 ms |
| Heating block supply voltage | 230 V AC (EN60204), 50/60 Hz |
| Solenoid valve supply voltage | 24 V DC, 8.0 W |
| Air connection (valve) | 5–6 bar, filtered, oil-free |
| Air consumption | approx. 8 ml per jetting element/cycle (5 bar) |
| Mounting | RO mounting bracket, 2× M6 left and right |
| Noise level | approx. 65–70 dB(A) |
| Protection rating | IP40 |
FK IT is used mainly in the printing and converting industries – on folding machines and for coating application onto sheets and continuous webs of material.
